6al 4v titanium round bar
2.Size: Diameter Φ6–Φ450mm, Length ≤ 6000mm (or customized up to 12000mm)
3.Standard: ASTM B348, ASME SB348, AMS
4928, AMS 6931, ASTM F136, ISO 5832-3
4.Type: Round bar
5.Processing Method: Vacuum melting → Forging → Hot rolling / Rotary forging → Centerless grinding / Turning → Straightening → Surface treatment
6.State: Annealed
7.Surface Treatment: Polished (bright), Turned (peeled), Centerless grinding, Sandblasted, Pickled
- Product Description
6Al 4V Titanium Round Bar - Premium Grade 5 Ti-6Al-4V Alloy
China's Titanium Valley is home to Baoji Jucheng Titanium Industry Co., Ltd., a National High-Tech Enterprise, has specialized in manufacturing 6al 4v titanium round bar for over 20 years. Our Grade 5 (Ti-6Al-4V) round bars have very high strength, with tensile strength of at least 895 MPa and yield strength of at least 828 MPa.The bars come in diameters from 6mm to 450mm and can be made to different lengths up to 12,000mm.
We make sure to deliver quickly for your important projects because we make over 500 sets of titanium equipment each year and always have more than 3,000 tons of titanium stock available.
To meet the standards of ASTM B348, AMS 4928, and ISO 5832-3, our bars go through strict processes like vacuum melting, forging, and precise grinding.
Key Advantages of Our 6Al 4V Round Bar
Superior Mechanical Performance
Reliability is essential for your applications. To achieve the ideal strength-to-weight ratio, our titanium alloy employs vanadium as a beta stabilizer and aluminum as an alpha stabilizer. The required flexibility for fastening applications is provided by the low elastic modulus of about 114 GPa.
Outstanding Resistance to Corrosion
Do you deal with industrial acids or seawater? Under conditions of severe oxidation and moderate reduction, this alloy remains stable. It does not significantly deteriorate at temperatures as high as 400°C (750°F).
Capability of Heat Treatment
Our 6al 4v titanium round bar reacts very well to solution treatment and aging (STA) procedures, in contrast to commercially pure titanium grades. This enables you to further improve fatigue resistance and hardness for specific needs.
Comprehensive Quality Control
Each batch goes through testing to check its mechanical properties, chemical makeup using ICP-OES, and ultrasonic inspection following AMS 2154 standards.Keeping oxygen levels below 0.20% helps prevent embrittlement.For full traceability, you get EN 10204 3.1 Material Test Reports.
 |  |  |  |
Technical Specifications Of 6al 4v titanium round bar
Parameter | Details |
Grade | Gr5 (Ti-6Al-4V), Gr23 (Ti-6Al-4V ELI) |
Diameter | Φ6–Φ450mm |
Length | ≤6000mm (customizable to 12,000mm) |
Tensile Strength | ≥895 MPa (130 ksi) |
Yield Strength | ≥828 MPa (120 ksi) |
Density | 4.43 g/cm³ |
Standards | ASTM B348, ASME SB348, AMS 4928, AMS 6931, ASTM F136, ISO 5832-3 |
State | Annealed |
Surface Finish | Polished, Turned, Centerless Ground, Sandblasted, Pickled |
 |  |  |
 |  |  |
 |  |  |  |
Wide Industry Applications
Our round bars are used in tough industries where performance is really important:
Aerospace: turbine blades, parts that hold the airplane together, and parts of the landing gear
Medical: implants for bones and tools used in surgery (Grade 23 ELI version)
Marine engineering: parts of propeller shafts and covers for underwater equipment
Chemical processing: fittings that don’t get damaged by chemicals and large containers where chemical reactions happen
High-end manufacturing: items like sports equipment and parts that are made with a lot of precision
 |  |  |
 |  |  |
Processing Excellence
Baoji Jucheng uses cutting-edge production techniques:
Vacuum Melting → Forging → Hot Rolling/Rotary Forging → Centerless Grinding → Surface Treatment → Straightening
Uniform microstructure with appropriate alpha and beta phase distribution is ensured by this regulated procedure. Your finished product is unaffected by coarse grain structures or alpha-case formation.
Why Choose Baoji Jucheng Titanium?
Our 41 utility model patents and 4 invention patents show how our creativity helps you succeed.We have a 120,000-square-meter production facility with a registered capital of RMB 50 million, making us the first private titanium company in Shaanxi Province to be listed on NEEQ.
We collaborate with Tsinghua University, Northwest University, and the Northwest Nonferrous Metals Research Institute to continuously enhance our technology.
Our experienced R&D teams ensure that every part of the production process is carefully improved.
We always have a 3,000-ton stockpile available for fast delivery, helping your projects stay on schedule.
We also provide complete after-sales support, offering technical assistance throughout the entire lifespan of your product.
FAQ
Q: What distinguishes Grade 23 (ELI) from Grade 5?
A: Grade 23 has Extra Low Interstitial concentration along with stricter oxygen and iron restrictions. Its remarkable fracture toughness and ductility make it ideal for cryogenic applications and medical implants.
Q: Is welding this material safe?
A: sufficient amount of argon or helium shielding is required to prevent oxygen pickup. Laser and electron beam welding produce the greatest outcomes for high-tech applications.
Q: Is 6al 4v titanium round bar difficult to machine?
A: Specific techniques are required due to its low thermal conductivity. Use high feed rates, low cutting speeds, enough of coolant, and sharp carbide tools to prevent job hardening.
Q: Which types of surface treatments are offered?
A: We provide centerless ground (h8, h9 tolerance) for precise work and peeled/turned surfaces for basic forging. The fatigue life of finished parts is extended by ground finishes.
Q: What is the maximum temperature at which it can be utilized?
A: The mechanical stability of your components is maintained up to approximately 400°C (750°F). Next, consider alloys with greater temperatures, like Ti-6242.
