GR5 Titanium Alloy Polished Wire

Baoji Jucheng Titanium Industry Co., Ltd. has been producing gr5 titanium alloy polished wire that meets the highest industrial standards for more than 20 years in China's Titanium Valley. Thanks to vacuum annealing, precision polishing, and multi-pass hot drawing, our Ti-6Al-4V polished wire has a tensile strength of over 895 MPa and a surface roughness (Ra) of less than 0.4μm. With a year-round inventory of about 3,000 tons of titanium, we guarantee prompt delivery of wire with diameters between Φ0.1mm and Φ8.0mm. Every year, our state-of-the-art production facilities create more than 500 sets of titanium equipment that meet AWS A5.16, ASTM B863, and ASTM F136 requirements for both standard and bespoke specifications.

What Makes Our GR5 Titanium Alloy Polished Wire Superior

The remarkable alpha-beta Ti-6Al-4V composition of the gr5 titanium alloy polished wire makes it stand out. This material offers the ideal ratio of strength to flexibility with 6% aluminum and 4% vanadium.

What really sets our product apart is the polishing process. Our centerless grinding and precision polishing remove the brittle alpha case layer, in contrast to conventional pickled wire. In demanding applications, this oxygen-enriched surface flaw frequently results in premature fatigue failure.

Wire with a mirror-like polish free of burrs and microcracks is beneficial for your projects. In settings that are high in chloride, the smooth surface improves corrosion resistance and reduces hydrogen embrittlement. Surface integrity has a direct impact on performance durability whether developing medical implants or aeronautical fasteners.

Hot drawing and vacuum annealing are included in our production process. This method preserves a modulus of elasticity of about 113.8 GPa while keeping the material's density at 4.43 g/cm³. The end product is wire that maintains structural integrity while withstanding high-cycle vibration.

Technical Specifications

Key Applications Across Industries

Aerospace Engineering: Materials resistant to galling during severe heat cycling are needed for high-strength rivets and bolts. In jet engine parts where temperature fluctuations surpass 500°C, the polished surface guarantees a smooth fit. Over several flight cycles, your fasteners remain dimensionally stable.

Medical Orthopedics: Biocompatibility and surface cleanliness are essential for surgical pins, bone staples, and dental fixtures. When compared to rougher surfaces, the polished finish can minimize bacterial adhesion by as much as 60%. This feature makes implant removal simpler and improves osseointegration for patient outcomes.

Marine Instrumentation: High salinity and high pressure are challenges for deep-sea research equipment. The polished surface of our wire prevents localized pitting corrosion and biofouling. At depths more than 3,000 meters, high-tension springs and sensor housings continue to work.

Additive Manufacturing: Regular wire feeding is necessary for Wire Arc Additive Manufacturing (WAAM) systems. The polished surface keeps automated machinery from jamming, guaranteeing continuous production runs. Your 3D-printed titanium parts have better mechanical qualities and layer adhesion.

Why Choose Baoji Jucheng Titanium

Our 120,000-square-meter manufacturing facility houses complete production and inspection systems. From titanium melting to non-destructive testing, every step undergoes rigorous quality control.

You gain access to our substantial inventory for immediate order fulfillment. Rush projects no longer mean compromised timelines. Our logistics team coordinates deliveries to match your production schedules.

We collaborate with Northwest Nonferrous Metals Research Institute and Tsinghua University. This partnership keeps our manufacturing processes at the industry's cutting edge. Your specifications benefit from the latest metallurgical research and process innovations.

Our 4 invention patents and 41 utility model patents demonstrate continuous innovation. As a National High-Tech Enterprise and Specialized "Little Giant" company, we invest heavily in R&D capabilities. Customized wire solutions for unique applications are our specialty.

Frequently Asked Questions

Q: What's the difference between polished and pickled titanium wire?

A: Polished wire undergoes mechanical surface treatment that removes the alpha case layer and achieves Ra < 0.4μm smoothness. Pickled wire only uses chemical treatment, leaving a rougher surface with potential micro-defects. Polished wire offers superior fatigue resistance and cleanliness for critical applications.

Q: Can you provide Extra Low Interstitial (ELI) grade wire?

A: Yes, we produce Gr23 (Ti-6Al-4V ELI) polished wire specifically for medical applications. This grade has reduced oxygen, nitrogen, and iron content, offering enhanced fracture toughness and biocompatibility compared to standard Gr5.

Q: What's your minimum order quantity for custom diameters?

A: We accommodate orders starting from 50 kg for standard diameters. Custom dimensions require minimum 200 kg orders due to tooling setup. Contact us to discuss your specific volume requirements and delivery schedules.

Q: How do you ensure consistent surface quality across production batches?

A: Every coil undergoes multi-point surface roughness testing using calibrated profilometers. We maintain statistical process control with real-time monitoring. Certificates of conformance include actual Ra measurements and tensile test results for full traceability.

Q: Is your wire suitable for high-temperature welding applications?

A: Absolutely. Our wire conforms to AWS A5.16 welding standards. The polished surface ensures stable arc characteristics and minimal spatter. It performs excellently in TIG and MIG welding processes up to 600°C without oxidation concerns when using proper shielding gas.

Contact Us for Your Titanium Wire Solutions

Ready to enhance your project with premium gr5 titanium alloy polished wire? Our technical team is standing by to discuss your specifications and delivery requirements. Reach us at s4@juchengti.com for immediate assistance.
